OSLO smart lock for inward-opening doors, Bluetooth, WiFi

Make your home smarter and more comfortable with the OSLO smart lock.

The OSLO smart lock from SMARTPASS is the perfect choice for doors that are operated with a key. The smart lock is invisible from the outside; it simply turns the existing lock into a smart lock, so you can easily take the first step toward a smart home.

With the OSLO model, you do not need to replace your existing lock, but install this smart lock on the inside of the door, so that the key is inserted into the mortise lock. The motor in the smart lock turns the key, thereby opening the door. This smart lock has an accessory, the so-called door closing sensor, which must be placed on the door frame; as soon as it detects that the door has closed, the smart lock turns the key and the door locks. In addition, you can set in the app how many seconds after opening the lock should close again; this should be at least 20 seconds.

Opening methods

• Via the app - within Bluetooth range or remotely via Gateway (the Gateway must be purchased separately, here)

• *With remote control – not included in the package, must be purchased separately here

• *With keypad - not included in the package, must be purchased separately here

Compatibility

• The Oslo smart lock is compatible with a euro profile cylinder.

• For inward-opening doors.

• It is important that the door has a cylinder into which the key can be inserted and turned from the outside even if the key is still in the keyhole on the inside.

• The cylinder must not protrude more than 30 mm from the plane of the door.

• The key for the lock must have the following parameters!

• A: ≤ 35 mm for symmetrical keys

• B: ≤ 45 mm for asymmetrical keys

• D: key thickness ≤ 4.5 mm

• E: no more than 17.5 mm from the center line (CL)
